Additional tank LRA 90L Toyota FJ Cruiser

The auxiliary tank LRA is designed for Toyota FJ Cruiser GSJ15R petrol Wagon 4WD body, from 2011 to 2012. With its capacity to 90 litersIt allows you to increase the vehicle's fuel range while retaining the original main fuel tank. This additional reserve is particularly suitable for long-distance journeys, expeditions, raids, and travel in remote areas.

The fuel tank is located behind the rear axle with a standard exhaust system. It features a dual filler neck, allowing independent fuel supply to both tanks. Fuel transfer to the main tank is achieved via an electric pump controlled from inside the vehicle by a switch with a dedicated fuel gauge. The spare tire remains in its original position, and no modifications to the exhaust system are required.

Since 1989, LONG RANGE AUTOMOTIVE designs and manufactures its tanks in Australia. Each model is developed for a specific vehicle application to optimize available volume while respecting the chassis's mechanical constraints. The tanks LRA They are made of 2mm T125CQ steel. They incorporate internal baffling to limit fuel movement, as well as an expansion chamber. Before being sold, they undergo pressure tests and several quality control checks. Tests are also carried out over dozens of kilometers of heavily degraded tracks. These tests verify the tank's resistance to vibrations, repeated twisting, impacts, and the stresses of prolonged off-road use.

Technical specifications:

- Type: Auxiliary tank
- Capacity: 90 liters
- Vehicle compatibility: Toyota FJ Cruiser GSJ15R
- Compatible years: 2011 to 2012
- Compatible engine type: Petrol
- Body type: Wagon
- Transmission: 4WD
- Required configuration: Model with original single tank
- Position: Behind the rear bridge
- Exhaust: Standard
- Filling point: Double filling point
- Transfer pump: Electric pump included
- Gauge: Switch with gauge LRA-PG210 supplied
- Spare wheel: Retained
- Estimated assembly time: 5 hours
- Made in Australia
